规格参数
型号 | 功率KW | 额定转速 | 电压V | 电流A | B | H | HD | L |
BS-15C30 | 15 | 30 | 380 | 26.7 | 395 | 200 | 510 | 1320 |
BS-18.5C30 | 18.5 | 380 | 32.9 | 318 | 430 | 510 | 1430 | |
BS-22C30 | 22 | 380 | 40 | 356 | 450 | 555 | 1410 | |
BS-30C30 | 30 | 380 | 54.6 | 356 | 450 | 555 | 1450 | |
BS-37C30 | 37 | 380 | 65.7 | 457 | 560 | 690 | 1390 | |
BS-45C30 | 45 | 380 | 80.6 | 457 | 560 | 690 | 1500 | |
BS-55C30 | 55 | 380 | 99.5 | 508 | 630 | 855 | 1720 | |
BS-75C30 | 75 | 380 | 135 | 508 | 630 | 855 | 1790 | |
BS-90C30 | 90 | 380 | 161 | 508 | 630 | 855 | 1890 | |
BS-110C30 | 110 | 380 | 191.3 | 686 | 960 | 1060 | 2010 | |
BS-132C30 | 132 | 380 | 229.5 | 686 | 960 | 1060 | 2120 | |
BS-160C30 | 160 | 380 | 278 | 686 | 960 | 1060 | 2170 | |
BS-200C30 | 200 | 380 | 344.9 | 710 | 990 | 1110 | 2410 | |
BS-250C30 | 250 | 380 | 430.5 | 710 | 990 | 1110 | 2500 | |
BS-315C30 | 315 | 380 | 565.7 | 950 | 1000 | 1400 | 2790 | |
BS-355C30 | 355 | 660 | 367.1 | 950 | 1000 | 1400 | 2970 | |
BS-400C30 | 400 | 660 | 409.3 | 950 | 1000 | 1400 | 3050 | |
BS-450C30 | 450 | 660 | 460.4 | 1060 | 1200 | 1510 | 3160 | |
BS-500C30 | 500 | 660 | 508.9 | 1060 | 1200 | 1510 | 3210 | |
BS-560C30 | 560 | 660 | 567 | 1060 | 1200 | 1510 | 3310 | |
BS-630C30 | 630 | 1140 | 367 | 1060 | 1200 | 1510 | 3390 | |
BS-710C30 | 710 | 1140 | 411.9 | 1120 | 1400 | 1730 | 3460 |
型号 | 功率KW | 额定转速 | 电压V | 电流A | B | H | HD | L |
BS-15C60 | 15 | 60 | 380 | 26.7 | 395 | 200 | 510 | 1150 |
BS-18.5C60 | 18.5 | 380 | 32.9 | 395 | 200 | 510 | 1240 | |
BS-22C60 | 22 | 380 | 40 | 435 | 225 | 555 | 1290 | |
BS-30C60 | 30 | 380 | 54.6 | 435 | 225 | 555 | 1280 | |
BS-37C60 | 37 | 380 | 65.7 | 550 | 280 | 690 | 1280 | |
BS-45C60 | 45 | 380 | 80.6 | 550 | 280 | 690 | 1340 | |
BS-55C60 | 55 | 380 | 99.5 | 628 | 315 | 855 | 1550 | |
BS-75C60 | 75 | 380 | 135 | 628 | 315 | 855 | 1580 | |
BS-90C60 | 90 | 380 | 161 | 628 | 315 | 855 | 1710 | |
BS-110C60 | 110 | 380 | 191.3 | 810 | 400 | 1060 | 1830 | |
BS-132C60 | 132 | 380 | 229.5 | 810 | 400 | 1060 | 1900 | |
BS-160C60 | 160 | 380 | 278 | 810 | 400 | 1060 | 1930 | |
BS-200C60 | 200 | 380 | 344.9 | 900 | 450 | 1110 | 2160 | |
BS-250C60 | 250 | 380 | 430.5 | 900 | 450 | 1110 | 2250 | |
BS-315C60 | 315 | 380 | 565.7 | 1130 | 500 | 1400 | 2520 | |
BS-355C60 | 355 | 660 | 367.1 | 1130 | 500 | 1400 | 2660 | |
BS-400C60 | 400 | 660 | 409.3 | 1130 | 500 | 1400 | 2800 | |
BS-450C60 | 450 | 660 | 460.4 | 1270 | 560 | 1510 | 2780 | |
BS-500C60 | 500 | 660 | 508.9 | 1270 | 560 | 1510 | 2920 | |
BS-560C60 | 560 | 660 | 567 | 1270 | 560 | 1510 | 3000 | |
BS-630C60 | 630 | 1140 | 367 | 1270 | 560 | 1510 | 3080 | |
BS-710C60 | 710 | 1140 | 411.9 | 1360 | 630 | 1730 | 3460 |
